25-237429

Bilstein B8 5160 w/ Remote Reservoir Shocks 25-237429

  • Sale
  • Regular price $199.00

In Stock

FREE Shipping Free Returns in the US Lower 48


Specifications

Part Number 25-237429
Extended Length 25.69"
Compressed Length 15.22"
Travel 10.47"
Top Mount STEM
Bottom Mount EYELET
Reservoir Yes
Color Silver
Finish Zinc Plated
Boot Included No
Gas Charged yes
Internal Design Monotube
Package Contains 1 Shock

Package Contains 1 Shock

You'll be getting one shock absorber.

Bilstein 2 Year Warranty

Bilstein 2 Year Warranty

Manufacturer Warranty protects against defects and premature failure.

Reservoir Mounts Included

Reservoir Mounts Included

All necessary washers, bushings, and nuts included. Factory shock mounting bolts are reused for installation. An optional billet aluminum reservoir clamp is available for a more clean and compact look.

Added external reservoir provides increased control and durability over the harshest terrain

Added external reservoir provides increased control and durability over the harshest terrain

Added external reservoir provides increased control and durability over the harshest terrain

Digressive valving provides increased control over unwanted body motions with increased bump compliance

Digressive valving provides increased control over unwanted body motions with increased bump compliance

Digressive valving provides increased control over unwanted body motions with increased bump compliance

Product Details

With an added remote reservoir, the BILSTEIN B8 5160 provides ultimate vehicle control on even the harshest terrain. Zinc plating and increased oil capacity dissipate more heat assuring long term durability. Reservoir mounts are included in the box. An optional billet aluminum reservoir clamp is available for a more clean and compact look.

We have the entire line of Bilstein products available, whether you want to upgrade, add a reservoir, or find something more affordable, contact us with any questions! 1-800-641-9161

Year Make Model Drive Position Lift
2018 Toyota Tundra 4WD, RWD Rear 0-1.5
2017 Toyota Tundra 4WD, RWD Rear 0-1.5
2016 Toyota Tundra 4WD, RWD Rear 0-1.5
2015 Toyota Tundra 4WD, RWD Rear 0-1.5
2014 Toyota Tundra 4WD, RWD Rear 0-1.5
2013 Toyota Tundra 4WD, RWD Rear 0-1.5
2012 Toyota Tundra 4WD, RWD Rear 0-1.5
2011 Toyota Tundra 4WD, RWD Rear 0-1.5
2010 Toyota Tundra 4WD, RWD Rear 0-1.5
2009 Toyota Tundra 4WD, RWD Rear 0-1.5
2008 Toyota Tundra 4WD, RWD Rear 0-1.5
2007 Toyota Tundra 4WD, RWD Rear 0-1.5
2019 Toyota Tundra RWD, 4WD, AWD, FWD Rear 0-1.5

We ship internationally, contact us for a shipping quote with your postal code.

Bilstein Warranty

Thyssenkrupp Bilstein of America warrants its gas pressure shock absorbers against defects in workmanship and materials for as long as you, the original purchaser, own your car.

If a shock, strut, or coil-over malfunctions and BILSTEIN determines it to be defective, we will either replace it or repair it, depending on the term of the warranty based on the assembly's model type.

BILSTEIN from the factory (original equipment), warranty claims must be directed to the vehicle manufacturer.


LIMITED LIFETIME WARRANTY

B4 OE Replacement / B6 / B6 Performance / B8 Performance Plus / B12 Series / B14 (PSS) / B16 (PSS9 & PSS10) / B6 4600 / B8 5100 / B8 5100 (Ride Height Adjustable) / B8 5112 / B8 6112

BILSTEIN warrants to the original retail purchaser that, for the life of each gas pressure shock, this product shall be free from defects in material and workmanship. Proof of purchase is required to process warranty. Please return product to the original place of purchase.


LIMITED 2 YEAR WARRANTY

B4 OE Replacement (Air) / Steering Racks
BILSTEIN warrants to the original retail purchaser that, for a period of two (2) years from the date of purchase, the B4 OE Replacement (Air) suspension and Steering Racks shall be free from defects in workmanship and/or material. Proof of purchase is required to process warranty. Please return product to the original place of purchase.


LIMITED 90 DAY WARRANTY


B8 5125 / B8 5150 / B8 5160 / B8 5165 / M 7100 Series / B8 8125 / M 9100 Series / M 9300 Series / BILSTEIN Clubsport® / MOTORSPORTS PRODUCT
BILSTEIN warrants to the original retail purchaser that, for a period of ninety (90) days from the date of purchase, this product shall be free from defects in material and workmanship. Any implied warranty of merchantability, fitness or fitness for particular purpose, except as may be prohibited by applicable law, is likewise limited in duration to ninety (90) days from the date of original retail purchase. Some States do not allow limitations on how long an implied warranty lasts so the above limitation may not apply to you.

This warranty is non-transferable and does not cover normal wear and tear or any other loss, liability or damage resulting from improper alteration, disassembly, handling, installation, service, repair or use of this product. Should this product fail as a result of a defect in materials or workmanship within the warranty period, contact BILSTEIN's Warranty Service Department by telephone at 1(800) 370-9522, or in writing at thyssenkrupp Bilstein of America 14102 Stowe Drive, Poway, California, 92064, for repair or replacement at Manufacturer's option. Do not return this motorsports product to the place of purchase. Proof of purchase is required to process warranty.


WARRANTY RESTRICTIONS

The limited warranties set forth above do not cover normal wear and tear and are non-transferable. The following are warranty exclusions:

Original equipment shock absorbers (vehicle manufacturer warranty) -Improper installation -Racing, driving competition or off-road use -Modified use or other than BILSTEIN recommended vehicles -Commercial vehicles -Bent or broken Rods showing abuse or abnormal wear

Surface finish, boot or mounting hardware such as, but not limited to, rubber bushings, as well as labor charges are not covered by any of the foregoing limited warranties. BILSTEIN's liability for a defective shock absorber is limited to replacement of shock with a new or reconditioned BILSTEIN shock absorber. Repair or replacement as provided by this warranty is customer's sole and exclusive remedy in the event of a product failure. Manufacturer shall not be liable for any incidental, consequential or other damages resulting from the disassembly, handling, installation, service, repair or use of this product. Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from State to State.

Note: Other exclusions may or may not apply in certain states or rare circumstances.
