2 Coilovers & 2 Rear Shocks
A full set of front strut & spring assemblies with the matched rear pair of shocks.Bilstein
B8 8112 ZoneControl CR Coilovers & Rear 8100 Shocks w/ Reservoir Set w/1.6-2.5" lift
2015-2026 Ford F-150 4WD
$3,750.60
3
Discount in Cart
Estimated Delivery in 8-12 weeks
Custom Order
All Bilstein 8112 / 8100 are constantly on order, please double check with our Sales team for availability if your needs are time sensitive. Otherwise wait times can be as long as 8-12 weeks.
Bilstein
B8 8112 ZoneControl CR Coilovers & Rear 8100 Shocks w/ Reservoir Set w/1.6-2.5" lift
2015-2026 Ford F-150 4WD
$3,750.60
3
Discount in Cart
Estimated Delivery in 8-12 weeks
Got Questions?
Our experts are here to help!
Part Numbers & Details
Bilstein 2 Year Warranty
Manufacturer Warranty protects against defects and premature failure.Lifts your vehicle 1.6-2.5" in the front
Springs will lift the vehicle 1.6-2.5" in the front and up to 0.5" in the rearExcludes Raptor Models
This will not fit a Raptor.Designed for 4WD vehicles
This product only works for 4WD vehicles.Without Continuously Controled Dampening
Excludes electronic suspensions.Reservoir Mounts Included
All necessary washers, bushings, and nuts included. Factory shock mounting bolts are reused for installation. An optional billet aluminum reservoir clamp is available for a more clean and compact look.ZoneControl CR
Position sensitive damping with 3 compression zones and 2 rebound zones, controlled by 3 independent pistons.Bilstein twin-tube technology
Twin-tube shocks utilize double-walled technology, where the piston divides the interior oil chamber into two working chambers. Under load, the piston pushes the oil down through the inner working chamber and up into the outer chamber. During rebound, the oil flows back through the piston valve to create a damping effect.Compression (C)
Provides bottom out control through a 2-stage, telescoping internal compression stop. This feature eliminates the need for an external hydraulic bump stop.Bilstein Gas-Pressure Technology
Traditional oil shock absorbers, when put under extreme stress, can lead to oil foaming which causes shock fading and results in damping power reduction. In the 1950s Bilstein found the solution to this problem by developing gas-pressure technology.Specifications
| Part Number | Item | Quantity |
|---|---|---|
| 25-316773 | Rear Shock | 2 |
| 41-326725 | Front Coilover | 1 |
| 41-326701 | Front Coilover | 1 |
| 25-326857 | Rear DSA Shock | 2 |
Product Details
The Bilstein 8112 and 8100 zone control shock set for the Ford F150 is one of the best performing shocks available today, whether you're searching for on-road comfort or offroad performance. Bilstein's unique design has blended the best of both worlds in a single package, allowing very comfortable on-road feel without sacrificing handling and control in the fast paced dirt environments.
Compatibility List
| Year | Make | Model | Drive | Position | Lift |
| 2026 | Ford | F-150 | 4WD | Front & Rear | 1.6-2.5 Front / 0-0.5 Rear |
| 2025 | Ford | F-150 | 4WD | Front & Rear | 1.6-2.5 Front / 0-0.5 Rear |
| 2024 | Ford | F-150 | 4WD | Front & Rear | 1.6-2.5 Front / 0-0.5 Rear |
| 2023 | Ford | F-150 | 4WD | Front & Rear | 1.6-2.5 Front / 0-0.5 Rear |
| 2022 | Ford | F-150 | 4WD | Front & Rear | 1.6-2.5 Front / 0-0.5 Rear |
| 2021 | Ford | F-150 | 4WD | Front & Rear | 1.6-2.5 Front / 0-0.5 Rear |
| 2020 | Ford | F-150 | 4WD | Front & Rear | 1.6-2.5 Front / 0-0.5 Rear |
| 2019 | Ford | F-150 | 4WD | Front & Rear | 1.6-2.5 Front / 0-0.5 Rear |
| 2018 | Ford | F-150 | 4WD | Front & Rear | 1.6-2.5 Front / 0-0.5 Rear |
| 2017 | Ford | F-150 | 4WD | Front & Rear | 1.6-2.5 Front / 0-0.5 Rear |
| 2016 | Ford | F-150 | 4WD | Front & Rear | 1.6-2.5 Front / 0-0.5 Rear |
| 2015 | Ford | F-150 | 4WD | Front & Rear | 1.6-2.5 Front / 0-0.5 Rear |
| Year | Make | Model | Drive | Position |
